| Capacity: | 2500BPH | Filling Type: | Piston Volumetric Filling,rotary Type |
|---|---|---|---|
| Machine Structure: | 2-in-1 Monoblock | Function: | Bottle Filling And Capping |
| Filling Valve: | Using Cam To Force Down | Power: | 2.0kw |
| Application: | Beverage, Food,commodity | Overall Dimensions (LxWxH): | 1900x1800x2200mm |
| High Light: | oil bottling equipment,motor oil filling machine |
||
Specifations
1. It's fully-automatic,it capacity is 2500 bottles per hour.
2. Pet bottle filling and capping 2-in-1 monoblock,piston volumetric filling,rotary type.
Features
1. Automatic 2-in-1 monobloc filling machine is suitable for filling shampoo,engine oil ,paste or oil
product, such as ketchup, jam,fruit and vegetable paste, cooking oil, honey, corn soup, peanut paste,
sauce. It also can be used for pulp, edible bird's nest, aloe, rice wine and so on.
2. The world famous brands of electrical and pneumatic components, low failure rate,long service life.
3. Automatic liquid detergent filling machine works stably, fills precisely, and suits for cold and hot filling.
The piston and piston barrel after the treatment of top technology cooperate accurately, durable and
wearable.
4. It is equipped with material stirring system, three point liquid level control, frequency conversion
adjustment, bottle in and out protection, automatic speed adjustment, filling with bottle and no filling
without bottles.
5. It adopts good stainless steel material, which meet the requirement of food sanitation. Vacuum pump
can make sure there is no dripping oil on bottle body or machine surface,keep the bottle and machine
clean.
Technical parameter
| Model | YGF12-4 |
| Capacity/1L BOTTLE | 2000-2500BPH |
| Filling head | 12 |
| Capping head | 4 |
| Filling time | 5 second(approx)(100ml/min) |
| Filling temperature | 18-20℃ |
| Filling tank | Semi closed type filling tank, using worm gear to adjust the height |
| Filling valve | Using cam to force down |
| Speed control | AC MOTOR+REDUCER+INVERTER |
| Gas consumption | 100NL/min(5-6Kg/cm²)(take 100EA as the base) |
| Power | 2.0Kw |
| Weight | 2000 Kg |
|
Overall dimensions(LxWxH) |
1900x1800x2200mm |
Note: the filling range and speed can be designed according to user needs to design
different filling head number.
