2500bph Monoblock Liquid Detergent Filling Machine For Dish Wash

2500bph Monoblock Liquid Detergent Filling Machine For Dish Wash
2500bph Monoblock Liquid Detergent Filling Machine For Dish Wash

Large Image :  2500bph Monoblock Liquid Detergent Filling Machine For Dish Wash

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: YGF12-4
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: PE film wrapping,Standard wooden boxes packaging
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Detailed Product Description
Capacity: 2500BPH Filling Type: Piston Volumetric Filling,rotary Type
Machine Structure: 2-in-1 Monoblock Function: Bottle Filling And Capping
Filling Valve: Using Cam To Force Down Power: 2.0kw
Application: Beverage, Food,commodity Overall Dimensions (LxWxH): 1900x1800x2200mm
High Light:

2500bph liquid detergent filling machine

,

monoblock liquid detergent filling machine

,

2500bph dish wash liquid filling machine



Liquid Detergent / Shampoo Automatic Oil Bottle Filling And Capping







Machine







Specifations



1. It's fully-automatic,it capacity is 2500 bottles per hour.



2. Pet bottle filling and capping 2-in-1 monoblock,piston volumetric filling,rotary type.





Features



1. Automatic 2-in-1 monobloc filling machine is suitable for filling shampoo,engine oil ,paste or oil



product, such as ketchup, jam,fruit and vegetable paste, cooking oil, honey, corn soup, peanut paste,



sauce. It also can be used for pulp, edible bird's nest, aloe, rice wine and so on.



2. The world famous brands of electrical and pneumatic components, low failure rate,long service life.



3. Automatic liquid detergent filling machine works stably, fills precisely, and suits for cold and hot filling.



The piston and piston barrel after the treatment of top technology cooperate accurately, durable and



wearable.



4. It is equipped with material stirring system, three point liquid level control, frequency conversion



adjustment, bottle in and out protection, automatic speed adjustment, filling with bottle and no filling



without bottles.



5. It adopts good stainless steel material, which meet the requirement of food sanitation. Vacuum pump



can make sure there is no dripping oil on bottle body or machine surface,keep the bottle and machine



clean.





Technical parameter



Model YGF12-4
Capacity/1L BOTTLE 2000-2500BPH
Filling head 12
Capping head 4
Filling time 5 second(approx)(100ml/min)
Filling temperature 18-20℃
Filling tank Semi closed type filling tank, using worm gear to adjust the height
Filling valve Using cam to force down
Speed control AC MOTOR+REDUCER+INVERTER
Gas consumption 100NL/min(5-6Kg/cm²)(take 100EA as the base)
Power 2.0Kw
Weight 2000 Kg

Overall dimensions(LxWxH)

1900x1800x2200mm



Note: the filling range and speed can be designed according to user needs to design



different filling head number.





Why Choose Jinyate?



1. Experience



Since1997,professional manufacturer of drinking water purification equipment, industrial pure water



equipment, ultrapure water equipment, seawater desalting plant, brackish water equipment as well as



bottled water production lines etc.



2. Quality Control



Haiguang machines all parts adopts CNC (computer numerical control machine tools) for



processing.Precision was improved greatly.



3. Reasonable Price



Haiguang machines are highest cost performance. Our machines and good service worth your cost.



4. Turn-Key Project



As a professional team, we have full experience in this field, our products have been widely exported to



different countries and regions. We have full oversea experience, not only for manufacturer, but also



installation and after service.



5. Fast Delivery



we have professional team, from design, manufacture, installation, and good quality control team to



ensure timely delivery.
