| Product Name: | Beer Bottle Filling Machine | Suitable Bottle: | Glass Bottle |
|---|---|---|---|
| Suitable Cap: | Crown Cap | Filling Material: | Beer, CSD Drink |
| Capacity: | 2000BPH(500ml) | Machine Type: | Split |
| Material: | SUS304 | Voltage: | 380V,50HZ,3Phases |
| High Light: | extrusion blow molding machine,pet stretch blow moulding machine |
||
Automatic Filling Machine For Packaging Beer With Glass Bottles, Soft Drink Plant
Introduction
1. Adopting the way of filling by holding the necks of the bottle, plus the function of pre-cover of the centralizing cover with high precise centralization, which ensure the right seating of mouth of the bottle and filling valve, with low liquid los
2. Adopting crowning the caps with magnetic force, which passes the torque with powerful and constant magnet, and the torque can be adjusted to meet the need of many kind of plastic caps.
3. Its easy to be maintained and used with the adopting of concentrating or automatic lubrication system and the structure of full-open protection.
Technical parameter
| Model | BGF12-12-6 |
| Rinser,filler,capper heads number | 12,12,6 |
| Volume of glass bottle | 0.3L-2L |
| Diameter of bottle | Φ50-108mm |
| Height of bottle: | 170-320mm |
| Filling precision | ±2-3% |
| PLC | Japanese Mitsubishi |
| Touch screen | Taiwan ARITAC |
Machine Pictures
rinser
filler
capper
besides this 2000BPH split machine, we also have other capacity, pls tell us your capacity
