Product Details:
Payment & Shipping Terms:
|
| Filling Pressure: | Balance Pressure | Capacity: | 2000BPH |
|---|---|---|---|
| Control: | PLC+touch Screen | Power: | 1.1kw |
| Bottle Material: | Can | Processing Type: | Cola,beer,carbonated Drink Ect. |
| Condition: | New | Driven Type: | Electric Driven |
| High Light: | beverage canning machine,small scale canning equipment |
||
Description:
It is mainly used in filling and sealing carbonated beverages as soft drinks, cola, sparkling wine, etc. It is
the ideal equipment for small-scale beverage factory.
Specification:
1. Overall feature:It’s designed on the basis of absorbing domestic and foreign advanced technology.Can
filling and sealing are realized by one machine.
2. It has such advantages as advanced construction, stable working, convenient operation and repair &
maintenance, transducer control as well as high production efficiency.
3. Machine materials:The main body of the machine is made of high quality SUS304 stainless steel. Main
components are processed precisely by CNC machine tool.
1) Production capacity: 2000 cans per hour
2) Bottle/can type:ф40-80
3) Power:0.55kw
4) Overall dimension:1200*500*1200mm
5) Weight:100kg
6) Voltage:380V/50HZ(can be adjustable)
2. DY-12 balanced filler
The filler is developed on the basis of digesting and absorbing advanced technology introducing from
abroad and wity international advanced level. It is mainly used for filling gas-containing drinks, such as
aerated water, cola, sparkling wine, fruit tea and so on. It is advanced in construction, steady in
performance, safe in operation, easy in maintenance high in production efficiency, and the speed can be
regulated infinitively. The filler is the ideal choice for drinks factories of small and middle type.
Main parameter
| Model | DY-8 | DY-12 | DY-18 | DY-24 | DY-32 |
| Production capacity | 1000-2000B/H | 1000-3000B/H | 2500-4600B/H | 2500-6000B/H | 3000-8000B/H |
| Bottle/cantype | glass bottle, PVC bottle, POP-Top can | glass bottle, PVC bottle, POP-Top can | glass bottle, PVC bottle, POP-Top can | glass bottle, PVC bottle, POP-Top can | glass bottle, PVC bottle, POP-Top can |
| Filling pressure | 0.2-0.3Mpa | 0.2-0.3Mpa | 0.2-0.3Mpa | 0.2-0.3Mpa | 0.2-0.3Mpa |
| Filling temperature | 2-6°C | 2-6°C | 2-6°C | 2-6°C | 2-6°C |
| Power | 0.75kw | 1.1kw | 1.5kw | 1.5kw | 2.2kw |
| Overall dimensions | 1000×900 | 1100×1050 | 1400×1300 | 1600×1540 | 1900×1500 |
| ×1800mm | ×1800mm | ×1800mm | ×1800mm | ×2000mm | |
| Weight | 1000kg | 1600kg | 2100kg | 2700kg | 3500kg |
3. FBZ-1 capper
1) Production capacity: 2000 cans per hour
2) Bottle/can type:ф40-80 Height:50-340
3) Power:0.75kw
4) Overall dimension:900*700*1800mm
5) Weight:350kg
6) Voltage:380V/50HZ(can be adjustable)
