150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation

150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation
150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation

Large Image :  150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation

Product Details:
Place of Origin: China(mainland)
Brand Name: JINYATE
Certification: CE SGS
Model Number: QGF-150
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PE film, standard wooden cases
Delivery Time: 35 working days
Supply Ability: 100 sets per year
Detailed Product Description
Product Name: 5 Gallon Water Bottling Machine Function: Washing Filling Capping
Model: QGF-150 Capacity: 150B/H
Bottle Size: 3-5 Gallon Filling Material: Mineral Water, Purified Water
Control: PLC+HMI Material: SUS304
Warranty: 1 Year
High Light:

20 ltr water jar filling machine

,

fully automatic filling machine



Small Industry 5 Gallons Automatic Purified And Mineral Water



Filling Machinery Price





product description





  • QGF series barreled production line is specially for producing 3 gallon and 5 gallon.
  •
  • Integrating with washing, filling and sealing, it is the ideal manufacturing equipment of
  •
  • mineral water and pure water.
  •
  • The main original electric parts are of SIEMENS and OMRON, the airflow system
  •
  • adopts imported Aortic products.
  •
  • Adopting excellent stainless steel, it is corrosion resistant and easy to clean.
  •
  • With the advantages of compact structure, small space occupation, high stable,
  •
  • reliable efficiency and high automation.
  •

Mechanism of the machine


1. Framework


Main supporter of the machine consists of stainless steel foursquare pipe with beautiful



appearance and firm structure. Subsidiary supporter which is joined to the main supporter



functions for separating the workaround and supporting.


2. Electric system


The electric part consists of PLC controller, AC contactor, Time Relay and Air Switch.


3. Pneumatic system


The pneumatic part consists of Cylinder, Pneumatic electromagnetic valve and pneumatic control



electric control box.





technical parameter



Item
Specification
model QGF-150
bottle size 3-6 gallon, 18.9litre
Capacity
150 barrels per hour
Electric part
SIEMENS Germany
Pneumatic parts
AIRTAC Taiwan
Power Supply
AC 380V±5%
AC 220V±5%
Rated Current
2A / 4A
Framework
45*75*2.0mm SUS304
Net Weight
2200kg
Motor power
2.2KW



product pictures



150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 0



150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 1



150BPH 5 Gallon Water Filling Machine Corrosion Resistant Small Space Occupation 2





The flowchart of 5 gallon water production



decapper—external brusher—internal brusher—5 gallon rising filling capping machine –cap shrink



machine—bagging machine



we can supply all these machines, just pls contact with us... ...
