|Filling Material:||Gas Liquid/carbonated Drink||Capacity:||2000BPH|
|Function:||Bottle Washing Filling Capping||Material:||Stainless Steel 304|
glass bottling equipment,
water glass filling machine
QS-12 DY-12 YG-6 machine includes QS automatic washer,DY balanced pressure filler,FXZ cap turning
machine,SSJ carrying machine ect.The key parts are made of stainless steel,with the features of
reasonable stucture,advanced technology,easy in operation,widely used,etc,it's the ideal machine for
middle and small beverage factory.
1.The bottleneck blocking makes the process of changing bottles easily by only adjusting the height of the
2. The filling process adopts micro-pressure technology, which makes filling process faster and more
3. Excellent Stainless Steel. Electric Components are of world known brand. All achieve national sanitary
4. PLC and transducers and othe main electric parts are of world famous brands, such as OMRON,
5. The line is composed by rotary washer, balanced pressure filler, screw type sealer and conveying
system. It is the ideal choice for small and middle scale drink factories.
1.The filler is developed on the basis of digesting and absorbing advanced technology introducing from
abroad and with international advanced level.
2.It is mainly usde for filling gas-containing drinks,such as aerated water,cola,sparkling wine,fruit tea and
so on,It is advanced in construction,steadly in performance,safe in operation,easy in maintenance high in
production effciency,and the speed can be regulated infinitively.
3.The filler is the ideal choice for drink factories of small and middle type.
Main technical parameter
|Model||QS-12 DY-12 YG-6|
|Number of washing head||12|
|Number of filling head||12|
|Number of capping head||6|
|Diameter of bottle||62-100mm|
|Height of bottle||160-320mm|
|Bottle/can type||glass bottle,PVC bottle,POP-top can|
|Cap type||crown type|
COMPONENTS BRAND LIST
|2||Frequency converter||Siemens, Germany|
|5||Touch screen||Siemens, Germany|
