PLC Control End Of Line Packaging Equipment With Adjustable Speed Range

China PLC Control End Of Line Packaging Equipment With Adjustable Speed Range supplier
PLC Control End Of Line Packaging Equipment With Adjustable Speed Range supplier PLC Control End Of Line Packaging Equipment With Adjustable Speed Range supplier PLC Control End Of Line Packaging Equipment With Adjustable Speed Range supplier PLC Control End Of Line Packaging Equipment With Adjustable Speed Range supplier

Large Image :  PLC Control End Of Line Packaging Equipment With Adjustable Speed Range

Product Details:

Place of Origin: China(mainland)
Brand Name: JINYATE
Certification: CE SGS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: standard wooden cases
Delivery Time: 35 working days
Supply Ability: 99 sets per year
Contact Now
Detailed Product Description
Product Name: Shrink Wrapping Machine Suitable Bottle: PET Bottle, Glass Bottle, Can
Package Material: PE Film Material: SUS304
Voltage: 380v 50hz Or Customized Weight: 3000kg



Automatic PP PE POF PVC Film Shrink Wrapping Machine For



Bottles, Cans







product description



1. HG-6030 is an economical fully-auto shrink wrapping machine by our company’s independent



research and development, which is widely used in mass production assembly line with auto-



feeding, conveying, sealing, shrinking in one time. It is high working efficiency and suits for the



products of different height and width;


2. The horizontal blade of sealing part adopts vertical driving, while the vertical cutter uses



international advanced thermostatic side cutter; The sealing line is straight and strong and we



can guarantee seal line in the middle of the product to achieve perfect sealing effect;



3.When it packs different sizes, the adjustment is very simple by rotating the hand wheel to



increase the reliability;


4. The machine adopts the most advanced Fatek PLC programmable controller, with safety



protection and alarm devices, while the sealing system can have a continuous sealing order



without replacement; Maintenance is very simple;


5. Feeding length controls through a combination of electric eye detection and time relay to



control precise film length that makes it easier to control the contraction effect;


6.Two groups of horizontal and vertical electric eyes are easy to switch for thin or small packages



which can easily complete sealing packaging operations;



Characters



  • Imported converter to achieve 0-12m/min. Adjustable speed range
  •
  • Large power double fan motor, assure enough circulate wind
  •
  • Ultrastrong cooling system to ensure quick formation after heat-shrinking of products
  •
  • Furnished with anchor bolts for integration with the production line





technical parameter



Packaging speed 12-18 bags/min
Working air pressure 4 - 6kg/cm2
The runnel Dimension(L*W*H) 1800*600*400mm
Max. packaging dimension(L*W*H) 450*450*350mm
Min. packaging dimension(L*W*H) 250*50*100mm
Conveyor belt level height(mm) 950±30mm
The machine dimension (L*W*H) 9500×990×1920mm
Packaging material PE,POF,PVC,PP
Power 5KW Adjuster
Weight 600kg



product pictures



PLC Control End Of Line Packaging Equipment With Adjustable Speed Range

PLC Control End Of Line Packaging Equipment With Adjustable Speed Range

PLC Control End Of Line Packaging Equipment With Adjustable Speed Range
