Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water

China Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier
Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water supplier

Large Image :  Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: QGF300

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard wooden boxes
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Dimension(L*W*H): 3800*1300*1600mm Capacity: 300BPH
Bottle Volume: 3-5gallon Weight: 1200kg
Processing Types: Normal Temperature Material: SS304
Control: PLC Filling Material: Flowing Liquid



Automatic 5 Gallon Filling Line 20L Jar Filling Machine For Pure Drinking Water







The complete 5 gallon water filling line:

1. Automatic decapper

2. Automatic external brusher

3. Automatic internal brusher

4. 5 gallon washing filling capping machine

5. Cap heat shrink machine

6. Light checker

7. Flat conveyor



Introduction:

The filling line specially produces 5 gallon barreled drinking water.It has the following types:80 type,150 type,300 type,450 type,600 type,900 type.It integrates bottle washer, filler and sealer into one unit. In order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer,washing solution can be used circularly.The sealer can seal barrel caps are aseptic and healthy,this line can also automatically carry out washing,sterilizing,filling, capping, counting and products discharging.It is a new kind of barreled water auto-producing line,which integrates mechanism, electricity and pneumatic technologies together.



Technical parameter

Model QGF-150 QGF-300 QGF-450 QGF-600 QGF-900
Filling heads 1 2 3 4 6
Volume 18.9
Barrel size 270*490
Capacity 150 300 450 600 900
Gas pressure 0.4 -0.6
Gas consumption 0.37 0.6 0.8 1 1.2
Motor power 1.75 3.8 3.8 7.5 9
Motor voltage 380V/50HZ
Weight 700 1200 1600 2000 3500
Dimension 2800*1100*1600 3800*1300*1600 4200*1600*1600 4800*1800*1600

4200*2300*1600

2800*1000*1600



Image show

Overall appearance

Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water



Washing part

The rinsing process includes 12 passes of procedures: 1. Pre-rinsing; 2. and 3. Rinsing with alkali liquor;
4. Dripping water; 5. and 6. Rinsing with water; 7. Dripping water; 8. and 9. Disinfectant solution; 10.
And 11. Finished water; 12. Dripping water.

Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water



Automatic Internal brusher

Automatic internal barrel brusher is a special supporting equipment for 5 gallon water production. It is
suitable for mineral water production, can effectively remove the sediment and algae materials inside the
barrel which caused by water mineralization itself.The machine improve the washing effect greatly and reduce
the second pollution by manually washing. The complete machine is made of super stainless steel, resist
corrosion and easy cleaning. Main electrical elements adopt Siemens or Omron, penumatic system adopt
Festo.It has a compact construction,high working efficiency and automation



Automatic 5 Gallon Water Filling Machine 20L Jar Filling Machine For Pure Drinking Water



Our service

1.One year warranty for the whole system.

2.Free equipment installation and debugging.

3.After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4.We can provide internship service and help you train the operator and mechanic.

5.Free beverage production technology and process configuration.

6.We can help you to design the product line, workshop and provide turn-key project.
