| Product Name: | Shrink Wrapping Machine | Suitable Bottle: | PET Bottle, Glass Bottle, Can |
|---|---|---|---|
| Package Material: | PE Film | Material: | SUS304 |
| Capacity: | 2-5bags/min | Package Model: | 12, 24bottles/bag |
| High Light: | heat shrink wrap machine,shrink sleeve labeling machine |
||
Semi - Automatic PE Film Heat Shrink Wrapping Machine With
Steam Generator
Introduction:
Semi automatic pe film shrink wrapping machine is suitable for wrapping pop-cans, bottles, etc,
both with bottom-tray and without bottom-tray, working with PE shrink tunnels.
The machine adopts the Germany advanced technology and international famous brands, which
makes capability stable and using long-time.
Characteristic:
1.Up and down magnetic switch prevent sealing mistakes, and protect the operators.
2 The input position is adjustable, base on the size of products packaged.
3.Schneider PLC, Schneider AC contractor, and Intelligent temperature controller performs
stable.
4.Large power conveyer motor, with stepless speed regulating, ensures smooth feeding.
5.Up and down large power fan system ensures the excellent effect of shrinking in one time.
6. Super cooling system cools the packing and makes the figuration perfectly.
7. The size of tunnel can be customized as your request.
Technical parameter:
|
Model
|
SLM
|
Model
|
BSE5040A
|
|
Power supply
|
220-240V, 50-60Hz;1.8KW
|
Power supply
|
3phase 220V/380V 50-60HZ
|
|
Capacity
|
2-5pcs/minute
|
Heater power
|
25KW Adjuster
|
|
Sealing time/shrink time
|
0.5-1.5s, 0-0.6s
|
Conveyer speed
|
0-10m/minute
|
|
Conveyor loading
|
30kg
|
Tunnel size(L*W*H)
|
1200*500*380mm
|
|
Film width
|
Max. 500mm
|
Conveyer loading
|
25Kkg MAX.
|
|
Film thickness
|
0.04-0.12mm
|
Shrink film
|
PE,POF,PVC,PP
|
|
Max. packing dimension(L*W*H)
|
450 x 270 x 350mm
|
Machine weight
|
250KG
|
|
Min. packing dimension(L*W*H)
|
250 x 60 x 60mm
|
Machine size
|
2200*780*1470mm
|
