| Name: | Water Bottling Machine | Function: | Rinser Filler Capper |
|---|---|---|---|
| Filling Heads: | 24 | Capacity: | 10000BPH |
| Material: | SUS304 | Control: | PLC+HIM+inverter |
| High Light: | 1000BPH pet bottle water filling machine,24 Heads pet bottle water filling machine,SUS304 drinking water bottle filling machine |
||
Automatic Bottle Filling Machine, Bottled Water Production Cost In Nigeria
Bottled water plant machinery:
1. (Making bottle) Full automatic bottle blow machine or Semi automatic bottle blow machine
2. (Water Filtration) RO water purification machine / UF mineral water filtration machine.
3. (Filling water into bottle) Bottle washing filling and capping machine.
4. (Labeling bottle water) Shrink sleeve labeling machine or Sticker labeling machine.
5. (Printing the date on the bottle water) Date printing machine.
6. (package the bottle water) Full automatic shrink wrapping packing machine or Semi automatic shrink wrapping packing machine / Carton box packing machine
Choose your production output per hour:
12-12-1 Bottle Water Washing Filling Capping Machine, Production:1000-2000 bottles per hour.
8-8-3 Bottle Water Washing Filling Capping Machine, Production:2000-3000 bottles per hour.
16-12-6 Bottle Water Washing Filling Capping Machine, Production:4000-5000 bottles per hour.
18-18-6 Bottle Water Washing Filling Capping Machine,5000-6000 bottles per hour.
24-24-8 Bottle Water Washing Filling Capping Machine,8000-10000 bottles per hour.
32-32-10 Bottle Water Washing Filling Capping Machine,10000-14000 bottles per hour.
Techinal parameter
| Model | CGF24-24-8 |
| Amount of working position | Rinsing 24, filling 24, capping 8 |
| Production Speed | 10000bottles per hour (500ml) |
| Pressure of air source | 0.3~0.7Mpa |
| Air consumption | 0.2~0.6M3/min |
| Pressure of rinse water | 0.06~0.2Mpa |
| Consumption of rinsing water | 1t/hour |
| Main motor power | 3.12kw |
| Dimension | 2760*2060*2700(L*W*H) |
| Weight | 4000kg |
Final product
