SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz

China SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier
SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz supplier

Large Image :  SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: CGF18-18-6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard wooden Boxes
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Capacity: 6000BPH(500ml) Weight: 3500kg
Power: 5.03kw Driven Type: Electric
Control: PLC+touch Screen Voltage: 380V/50Hz
Packaging Type: Barrel, Bottles Filling Temperature: Room Temperature



SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz




CGF18-18-6 three-in-one machine for PET bottle integrates the functions of rinsing, filling and capping together. Based on advanced technology overseas and designed according to the filling processing demands of mineral water, pure water etc.

Working process
Bottles are fed from air conveyor into three-in-one rinsing machine via star-wheel. Bottle clamp installed on the rotary wheel of the rinsing machine will grip bottle mouth and make 180º turn along a guide track to face the bottle mouth downward.
In designated section of the rinsing machine rinsing water will jet out from special nozzles to flush bottle inside wall. After rinsing and dripping, bottles gripped by bottle clamp will make another 180º turn along a guide track to resume bottle mouth facing up.
Cleaned bottles are moved out of the rinsing machine by star-wheel. After entering the fill area, bottles are retained by neck supporting carrier plates which are actuated by bottle carrier mechanism to raise them to engage with filling valves.
Filling is completed by gravity. The material filled into the bottle through filling valve. The bottle goes down and leaves valve to capping machine via neck handling star-wheel.
Anti-rotation blades on capping heads will seize the neck of bottle to prevent it from rotation and hold it in up-right. The twist-on capping head will make revolving and rotating movement along with the machine to finish the complete capping process of cap picking, placing, twisting and disengaging under the control of a cam.

Main features
1. This machine has a compact structure, perfect control system, easy to operate and highly automated.
2. Only by changing the star-wheel, arch board can realize fill bottle shape change
3. The parts contact with product is made of quality SUS, anti-corrosive, and easy to clean.
4. Rapid flow, highly filling precision, nicety liquid level without any liquid loss to satisfy the filling process demand.
5. The capping head adopts constant torque magnetic device to guarantee capping quality and impact cap.
6. This machine has a high efficient cap arranging system, perfect cap feeding with self-control and self-protection device.
7. The machine adopts perfect overload protective device can ensure the operator and machine safety
8. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
9. The main electric and air-drive components are world famous brand products.
10. All control is advanced touch-screen operation and realize people-computer dialogue operation.



Technical parameters

ModelCGF16-12-6CGF18-18-6CGF24-24-8CGF32-32-10
Production capacity(500ml)(b/h)2000-40004000-60008000-1000012000-15000(0.5L)
Filling precision≤±5MM(Liquid Level)
Polyester bottle standard(mm)Bottle diameter40-80;
HeightHeight:130-280(Height):150-320
Suitable cap shapePlastic Screw Cap
Water pressure of Washing bottle(MPa)0.18
Water consumption for Water bottle (kg/h)800160025003500
Spraying position55612
Dripping bottle position333.57
Gas source pressure(Mpa)normal pressure
Gas consumption(m3/mm)0.30.30.40.5
Total power4.235.036.578.63
Total weight2000350055008000
Dimension(L*W*H)mm2100×1500×22002450×1800×22002750×2180×2200

3500×2200×2250




SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz
SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz
SS304 500ml Water Bottle Filling Machine Mineral Water Plant 380V / 50Hz
