20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface

China 20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface supplier
20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface supplier 20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface supplier 20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface supplier 20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface supplier

Large Image :  20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface

Product Details:

Place of Origin: China(mainland)
Brand Name: JINYATE
Certification: CE SGS
Model Number: JYT

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: standard wooden cases
Delivery Time: 35 working days
Supply Ability: 99 sets per year
Contact Now
Detailed Product Description
Products Name: Bottle Blow Molding Machine Usage: Make PET Bottle
Type: Full Auto Material: Stainless Steeel
Bottle Size: 500ml-5L Warranty: 1 Year



Plastic Injection Stretch 20 Liter Bottle Blow Molding Machine





1.Product Description



This 20L blow molding machine is suitable to produce HDPE, LDPE, PP bottles which is under



20 liters. This machine could install parison controller to enhance the bottle quality. It is controlled



by PLC system, all the temperature controller are controlled by touch screen interface. Move



moulds and blow process is faster after enhanced the technology to straight type guide rail, so



the production capacity of this machine has been increased apparently.





construction



Station A:Preform injection



The bottle neck will be molded accurately after injecting the material into the cavity,After proper



control,the mold open and mandrils to...along with the cavity.



Station B:Blow molding



Blowing action was done at this part,molding would be complete after cooling.(bottle shape



decides by the mold cavity).The air came out from the mandrils huffs the cavity,make the cavity



cling to the mold.Then mold open and the mandrils turn to...along with bottles.



Station C:Stripper



The bottle automatically will be ejected from the mandrils at this position and then to be



packed.The three actions of injection/blowing/ejection working at the same time,which makes the



machine of high efficiency and low waste with bottles.



technical parameter


System Item Unit Basic Parameters
Basic Plastic fit for   PE/PP
Max hollow product volume L 20L
No. of Die head SET 2
Size(LxWxH) M 3.6*2.5*2.4
Weight TON 5
Production Capacity Pc/Hr 400-500
No. of Working Station Set 2
Molds Clamping Force KN 120
Extrusion System screw diameter MM 75
Screw L/D ratio L/D 25:1
Screw fan's power KW 0.56
Extrusion motor's power KW 18.5
Die head Die head heating zone zone 2
Die head heating power KW 13.5
Sprue-die dia.(max) mm 180
Power General Power KW 65.7
Oil-pump motor power KW 7.5
Compressed air m³/min 0.5—0.6 8KG
Cooling water L/min 3--5


product pictures

20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface


20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface
20 Liter PET Blow Moulding Machine Plastic Injection Stretch With Touch Screen Interface
