Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling

China Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling supplier
Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling supplier Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling supplier Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling supplier Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling supplier

Large Image :  Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling

Product Details:

Place of Origin: China(Mainland)
Brand Name: JINYATE
Certification: CE SGS
Model Number: BCGF

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: standard wooden cases
Delivery Time: 35 working days
Supply Ability: 90 sets per year
Contact Now
Detailed Product Description
Product Name: Glass Bottle Beverage Filling Machine Filling Material: Water, Juice, Tea Or Other Non-gas Liquid
Function: Rising Filling Capping Suitable Bottle: Glass Bottle
Machine Model: BCGF8-8-3 Capacity: 2000B/H
Control: PLC+Touch Screen Voltage: 380V 50hz



250ml 500ml 1.5L Fruit Juice Glass Bottle Filling And Package



Machine For Sale







product description



this glass bottle beverage machine is for non-carbonated drink filling, like water,



juice,coffee and milk beverage, etc. It integrates rising filling capping 3 functions in



one unit. this machine has 8 rising heads, 8 filling heads and 3 capping heads, can



filling 2000 bottles per hour.



technical parameter



model BCGF8-8-3
Suitble bottle Glass bottle
Filling material Water, juice, tea, milk
Fillingi type Normal pressure filling
Rising/filling/capping heads number 8/8/3
capacity 3000B/H(for 500ml)
voltage 380V 50Hz or customized
Material SUS304
Dimension 1900*1500*2200mm
weight 2000kg





























component construction



1. bottle inlet conveyor



2. bottle outlet conveyor



3. cap loader



4. rising



5. filling



6. capping



product pictures



overall look



Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling



inner look



Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling



eletrical system



Fruit Juice Glass Bottle Filling Machine 500ML 1.5L Normal Pressure Filling



Beside this BCGF8-8-3, we also have other capacity



Model BCGF16-12-6 BCGF18-18-6 BCGF24-24-8 BCGF32-32-10 BCGF40-40-12 BCGF50-50-15
Number of rising heads 16 18 24 32 40 50
Number of filling heads 12 18 24 32 40 50
Number of capping heads 6 6 8 10 12 15
Bottle standard(mm)

Diameter:Φ50-Φ108

Height:150-320

Rated production capacity(500ml) 4000BPH 6000BPH 10000BPH 12000BPH 16000BPH 24000BPH
Installed capacity(KW) 3.8 4.3 6.5 8.7 9.5 12
