QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

China QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage supplier
QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage supplier QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage supplier QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage supplier QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage supplier

Large Image :  QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

Product Details:

Place of Origin: China(mainland)
Brand Name: JYT
Certification: CE SGS
Model Number: QHS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: standard wooden cases
Delivery Time: 35 working days
Supply Ability: 99 sets per year
Contact Now
Detailed Product Description
Product Name: CO2 Mixer Usage: Beverage Mixing
Mixing Rage: 1:3-1:6 Working Pressure: 0.05-0.08
Capacity: 2T-10T/H Material: SUS304



QHS-2000 Carbon Dioxide Mixer, Carbonation Machine / Soft



Drinks Mixer



product description



industrial CO2 beverage mixer , which were developed pn the base of advanced similar



technologles abord, are mainly appliciable for mixing water-syrup-CO2 proportionally in beverage



industry. industrial CO2 beverage mixer is the most advanced Beverage Mixer in this field at



present.



There is a set of advanced water-gas mixing device on the machine. This industrial CO2



beverage mixer could proportionally mix syrup, additive, drink water and CO2 into finished



beverage before bottling. The iindustrial CO2 beverage mixer also could thin beer or aerate beer



or produce sparking wine before bottling.



technical parameter



Model QHS-1500A QHS-3500A QHS-3000 QHS-5000 QHS-7000 QHS-10000 QHS-15000
Capacity(L/hr.) 1000-1500 2000-3500 2000-3000 4000-6000 8000-9000 10000-12000 12000-16000
Gas content in beverage(GV) 1.5-2.5 1.5-2.5 >3.0 >3.0 >3.5 >3.5 >3.5
Mixing range(Syrup-water) 1:3-1:6 1:3-1:6
Tempeature in chilled water 0-5ºC 0-4ºC
Water deoxidization method Deoxidized by CO2 Deoxidized by vacuum system
Working pressure of pre-carbination tank and syrup tank(Mpa) 0.05-0.08 Pre-carbonation tank:-0.08~-0.06
Syrup tank:0.05~0.08
Working pressure in storage tank(Mpa) 0.2-0.5 0.2-0.5
Power supply(kw) 1.1 1.5 3.70 5.2 8.5 11 15
Overall dimension(mm) 900*700*2000 1100*900*2100 1600*1200*2100 2000*1500*2200 3200*2100*2500 3800*2200*2750 4300*2200*2550
Weight(kg) 500 650 1200 1800 2800 4800 6500



Products Structure and Working Procedur



(1). CO2 tank, syrup tank, liquid level device, static mixing device, tank, electrical controlling



system, air providing tank, and necessary producing pipe and cleaning pipe including ball valve,



magnetism valve, check valve are composed this machine. (See photo 1: main structure)



(2). Main working Procedure



a. Cooling water→multi-grade pump→oxygenating CO2→volume control



b. Cooling syrup→multi-grade pump→syrup tank→volume control



(a and b → multi-grade pump→static mixing device→



c. CO2 air resource→filter and pressure reducing→ tank→filling machine







product pictures



QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage
