220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle

Certification
Good quality Water Bottle Filling Machine for sales
Good quality Water Bottle Filling Machine for sales
Customer Reviews
Your machine quality is very good and technical team very professional, hope our products sell well!

—— Shiferaw Habte

I have worked with them for five years, their juice and carbonated machine help me spread my busniess acorss Africa, this year we place an 24000BPH carbonated line, looking forward to the machine installation in our factory early.

—— Umesh

I'm Online Chat Now

220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle

China 220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier
220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier 220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier 220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier 220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier 220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle supplier

Large Image :  220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE ISO SGS
Model Number: QS-12 CYG-12 FXZ-1

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard wooden boxes
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Dimension(L*W*H): 1100*1050*1800mm Weight: 1600kg
Filling Pressure: Normal Pressure Capacity: 2000BPH
Function: Bottle Washing Filling Capping After-sales Service Provided: Engineers Available To Service Machinery Overseas
Voltage: 220V/380V Bottle Type: PET Plastic Bottle
Power: 2.25kw Filling Material: Water



Water Bottling Machine,Small Scale Beverage Filling Machine With 1L



Pet Bottle





Specifications:



1. small water bottling machine,water bottling machine



2. small scale filling machine



3. water filling machine



4. 1L pet bottle



The production line includes QS auto washer,CYG often pressure filter,FXZ cap turining machine,SSJ



carrying machine etc.The key parts for washing,filling and sealing are made of high quality stainless



material,with the features of advanced technology,completed system,reliable performance,easy in



operation,etc.



Main parameter



Model Production Bottle Height Motor power
QS-12 CYG-12 FXZ-1 2000-3000b/h 160-300mm 2.25kw
QS-18 CYG-18 FXZ-6 3000-6000b/h 160-320mm 2.95kw
QS-24 CYG-24 FXZ-8 3000-8000b/h 160-340mm 3.7kw



Application:



1. This CGY Series Wash-filling-capping 3-in-1unit is used to produce polyester bottled mineral water,



purified water, alcoholic beverage machinery and other non-gas beverage machinery. It can finish all the



process such as press bottle, filling and sealing, it can reduce the materials and outsiders touch time,



improve the sanitary conditions, production capacity and economic efficiency.



2. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw



and conveyor chains, this enable the change the bottle-shaped become easier.



3. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the



equipment level, only change related the curved plate, wheel and nylon parts is enough.



4. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with



the screw location of bottle mouth to avoid secondary pollution.



5. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.



6. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor



chains.



7. Host adopts advanced PLC automatic control technology, the key electrical components from famous



company such as Japan's Mitsubishi, France Schneider, OMRON.



Filling part



220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle



Capping part



220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle



Our worker is welding



220V / 380V Water Bottle Filling Machine Clip Bottleneck Technology With 1L Pet Bottle



COMPONENTS BRAND LIST



1 PLC Siemens, Germany
2 Frequency converter Siemens, Germany
3 Contactor Schneider
4 Circuit breaker Schneider
5 Touch screen Siemens, Germany
6 Buzzer Schneider
