Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling

China Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling supplier
Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling supplier Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling supplier Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling supplier Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling supplier

Large Image :  Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: YGF18-6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: PE film wrapping,Standard wooden boxes packaging
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Capacity: 3000BPH Filling Material: Oil,Sauce,Vinegar,fruit&vegetable Paste
Function: Filling ,capping Power: 2.2kw
Weight: 2000kg Overall Dimensions (LxWxH): 1900x1800x2200mm
Condition: New Driven Type: Electric+pneumatic



250ml-2l Bottle Palm / Peanut Oil / Honey Piston Volumetric Filling



Machine







Specifations



1. 2-in-1 Rotary type,Piston volumetric filling



2. This 2-in-1 unit machine is suitable for filling paste or oil product, such as ketchup, jam, fruit



and vegetable paste, cooking oil, honey, corn soup, peanut paste, sauce. It also can be used for



pulp, edible bird's nest, aloe, rice wine and so on.





Features



1. It can be used for fixed amount small package filling,straight line type



filling,mechamcal,electric,apparatus control of all sorts of viscous and nonviscous,erosive liquid,such as



plant oil chemlcal,liquid,daily chemical industry.



2. It is rather simple and rapid to change items,the design is quite distinct,the property is Very



advantageous,its appearance corresponds to international concept for mechanlcal equlpment.



3. It has applied SIEMENS PLC computerlzed control,from germany. It has intellectual,protection function.



4. Vacuum drop prevention device guarantees there Should be absolutely no drop or leakage during



production.



5. It works stably, fills precisely, and suits for cold and hot filling. The piston and piston barrel after the



treatment of top technology cooperate accurately, durable and wearable.



6. It is equipped with material stirring system, three point liquid level control, frequency conversion



adjustment, bottle in and out protection, automatic speed adjustment, filling with bottle and no filling



without bottles.



7. It adopts good stainless steel material, which meet the requirement of food sanitation.



8. Vacuum pump can make sure there is no dripping oil on bottle body or machine surface, keep the



bottle and machine clean.





Technical parameter



Model YGF18-6
Capacity/1L BOTTLE 3000BPH
Filling head 18
Capping head 6
Filling time 5 second(approx)(100ml/min)
Filling temperature 18-20℃
Filling tank Semi closed type filling tank, using worm gear to adjust the height
Filling valve Using cam to force down
Speed control AC MOTOR+REDUCER+INVERTER
Gas consumption 100NL/min(5-6Kg/cm²)(take 100EA as the base)
Power 2.2Kw
Weight 2000 Kg

Overall dimensions(LxWxH)

1900x1800x2200mm



Final products



Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling



Filling part



Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling



Capping part



Palm / Honey Auto Oil Filling Machine 2 In 1 Rotary Type Piston Volumetric Filling



SERVICE
One year warranty for the whole system.
Free equipment installation and debugging.
After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
We can provide internship service and help you train the operator and mechanic.
Free beverage production technology and process configuration.
We can help you to design the product line, workshop and provide turn-key project.
