| Product Name: | Can Filling Machine | Filling Product: | Carbonated Soft Drink, Beer, Cola |
|---|---|---|---|
| Capacity: | 500-1500 Cans/hr | Driven Type: | Electric |
| Application: | Beverage | Material: | SUS304 |
| High Light: | Beer can filler seamer,SUS304 can filler seamer,SUS304 can filling line |
||
Can Filler And Seamer, Canned Beer Manufacturing Plant, Beer Canning Line
The mixing proportion is accurate and easy to adjust. And the machine can easily adjust the proportion of syrup with water in the product without change any parts.
| No. | Item | Parameter |
| Filling material |
cola, soda, energy drink, soft drink, sparkling water, fizzy drink, tonic water, beer
|
|
| 1 | Max. Capacity | 500-1500cans/hr |
| 2 | Filling valve | 12 |
| 3 | Seaming head | 1 |
| 4 | Filling temperature | 2-4℃ |
| 5 | Filling method | Pressure equalization |
| 6 | Exhaust oxygen device | CO2 automatic purge of displacement |
| 7 | Beer bowl up, down regulation system | electric |
| 8 | Filling level accuracy | ±2mm |
| 9 | Working type | Filler driving force from seamer |
| 10 | Inlet and outlet of the direction of can | 360 degrees |
| 11 | Total power | 2.5KW |
We also have filling capping 2 in 1 machine
|
Model
|
12-4
|
18-4
|
20-6
|
30-6
|
|
Filling head
|
12
|
18
|
20
|
30
|
|
Capping head
|
4
|
4
|
6
|
6
|
|
Capacity(BPH)
|
150
|
250
|
150
|
250
|
|
Diameter of can(mm)
|
52.5-99
|
52.5-99
|
52.5-99
|
52.5-99
|
|
height of can(mm)
|
39-160
|
39-160
|
39-160
|
39-160
|
|
power(kw)
|
5.5
|
5.5
|
5.5
|
7.5
|
|
weight(kg)
|
3100
|
3800
|
4000
|
6000
|
|
Dimension(mm)
|
2700*1400*1900
|
3050*1750*1900
|
3400*1950*1900
|
3900*2400*1900
|
Should you have any questions, pls do not hesitate to contact us any time!
