Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper

Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper
Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper

Large Image :  Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper

Product Details:
Place of Origin: CHINA
Brand Name: JINYATE
Certification: CE
Model Number: BRCGF8-8-3
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: pleaes inquire
Packaging Details: standard export package
Delivery Time: 45 working days
Supply Ability: 100 sets a year
Detailed Product Description
Name: Pulp Juice Filling Machine Function: Rinsing, Filling, Capping
Suitable Bottle: Glass Bottle Bottle Volume: 200-1000ml
Suitable Cap: Twist-off Cap, Screw Cap Capaicty: 3000BPH
Voltage: 380V Or Customize Weight: 2500KG
High Light:

glass bottling equipment

,

water glass filling machine

Description:

This machine is used to produce glass bottle various juice, which combines ringsing, juice filling, pulp filling and capping four stations in one unit.

Specially the seperate pulp station guarantees the machine can fill big pulp.



Techinial parameter:

Model BRCGF8-8-1-3
Rated capacity

300-500ML:3000B/H; 1000ML:1500B/H

Speed adjustable
Filling Liquid Juice with big pulp
Filling Container Type

glass  bottle: Max Diameter 108mm,

                     Max Height 310mm

Filling Type Gravity filling
Cap twist-off cap, screw cap, ring-off cap, crown cap
Filling Temperature ambient Temperature
Label Material Adhesive Label; OPP Label
Conveyor Mode

Conveyor Belt

Factory Condition

Temperature:10~40℃

Humidity:no dew(≤95%)

Resource Voltage According Customer ' s Factory Voltage Design.
Efficiency > 9 5 %
Control PLC+HMI
Voltage 380V 50HZ 3Phases or customized



Machine picture

washing:

1. The washing part is mainly composed of water distributor, bottle clamp, up turnplate, guide rail, protection cover, spraying device, defrosting tray.
2. The high efficiency atomizing spay nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and also saves rinsing water.

Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper 0

juice filling

1. Filling device is mainly composed of filling barrel, filling valve, guide rail, elevating device, elevating device, etc.
2.Gravity filling method
3.Filler is driven through gears inside the machine frame.

Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper 1



Pulp filling:

Automated Glass Bottle Filling Machine , Juice Making Plant , Monoblock Filler And Capper 2



We have rich experience in glass bottle juice package machine, can provide complete line plants, capacity starts from 1000 bottles per hour to 30000BPH, also can customize the equipment according to your request, please contact... ...
