Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine

China Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier
Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine supplier

Large Image :  Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: DGF12-6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard Wooden Boxes
Delivery Time: 30-45 working days
Supply Ability: 10 Set/Sets per Month
Contact Now
Detailed Product Description
Power: 5.03kw Overall Dimension(L*W*H): 2100*1500*2200mm
Warranty: 1 Year For Free Material: Food Grade Stainless Steel 304
Voltage: 380V 50Hz Driven Type: Electric
Filling Pressure: Balanced Pressure Filling Filling Material: Gas Contained Beverage

Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine


Plastic bottled carbonated drink filled

Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine

Features of carbonated drink filling machine

1. It combines filling and capping as one automatic body suitable for PET or other plastic bottles.

2. The serious filling machine is used in production gas containing water of PET polyester bottle-packing carbonated beverage, such as Coca cola, Pepsi-cola, Spirit drink etc.

3. The bottle neck blocking makes the process of changing bottles easily by only adjusting the height of conveyor chain.

4. Designing reasonable. The appearance is beautiful and the maintenance is convenient. Autoamtic filling machine adopts bottle handing technology to make changing bottle more convenient, faster and easier. The main machine adopts advanced PLC control, touch screen and no-bottle, no-cap system elements are famous international brand.

5. The filling process adopts the micro-pressure technology,which makes filling process faster and more stable.

6. The iso-pressure (iso-barometric) filling technology is adopted enabling it to fill more efficiently and more stably with more output than the machine of the same level from others.

7. Capping part is mainy use the cap that ordering in cap unscrambler,and capping on the finished fill bottle,and then deliver to the followed procedure.



Technical parameter

Model: DGF12-6 DGF18-6 DGF24-8 DGF32-10
Capacity :(BPH)500ml 2000-4000 4000-6000 6000-8000 8000-12000
Bottle shape: rouNd or square
PET bottle: (mm) (Bottle Diameter):φ50-.φ110mm (Height):150-340mm
Cap: PE srew cap
Filling precision: ≤±5mm
Filling pressure:(Mpa) 0.15-0.35
Rinsing pressure:(Mpa) 0.2-0.25
Power(KW) 5.03 5.03 6.57 8.07
Overall size:(mm) 2100*1500*2200 2450*1800*2200 2750*2180*2200 3600*2200*2600
Weight: (kg) 2000 3000 4000 5000



Overall look

Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine

Filling part

Carbonated Sparkling Water / Carbonated Drink Filling Machine Soft Drink Filling Capping 2-in-1 Machine

24 hours customer service line
Experienced answer and focused professional support
Customized service solution

1.Bottle Design Service

Our engineer can design different bottle drawing for your reference!
Contact Us: We will send design drawing!

2.Layout Design Service

We supply standard layout for each water filling machine line, also available for customize design layout based on Customers Factory Area!
Give US: Factory Area

3.Label Design Service
Design colorful label for customers’ choice
Provide Us: Information wants to put on label

Before Sales service provided

1. Answer your any question on us within 24 hours.
2. Supply all information you required.
3. Machines video for reference
4. Welcome to visit factory

On Sales service for you

1. Update production progress each week
2. Sending machines pictures on production
3. Machines testing running over 8 hours, and sending testing videos

Good after-sale service offered

1. Professional QC and engineer team
2. Installation on site and free technology training
3. Perfect spare parts supply system
