| Condition: | New | Processing Type: | Water |
|---|---|---|---|
| Material: | Stainless Steel 304 | Driven Type: | Driven Type |
| Warranty: | One Year For Free | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Color: | Silver Gray | Function: | Removing Impurities From The Water |
| High Light: | water treatment machine,water purification equipment |
||
Detail Introduce
Water treatment:
1, desalt rate ≥99
2, capacity: 500-50000LPH
3, material: 304 S.S
4, Conductivity≤20
Jiayuan Reverse Osmosis RO System Water Treatment is for producing drinking water, foods factory, beverage factory, fruit& vegetable factory etc. The machine is integrated into a group, the assembly and transportation are rather convenient.
It's simply operation and has long lifespan.
Main components: RO membrane(Hydecanme),
high pressure pump(NANFANG China)
Electricity conduction meter
Over high or over low pressure protection failities
304 Stainless steel
Suitable for investment for mid-scale enterprises
The standard of supplied water
Electricity conduction rate: Nor more than 10us/cm
Bacteria no.: Not more than 20
Installation:
Raw water pump+quartz and sand filter +active carbon filter +sodium ion filter + precision filter +high pressure pump +RO system+Ozone generator+water storage tank.
Plant process:
1. Raw water pump-- provide the pressure to silica sand filter/active carbon filter
2. Quartz and Sand filter-- get rid of turbidity, suspended matter, organic matter, colloid and so on
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter and so on
4, Sodium ion filter--reduce the hardness of water
4. Precision filter--prevent any deposition of large Particles, most of the bacteria, and viruses into the RO membrane, The accuracy is 5um, for holding back any large particulates such as large iron, dust, suspended matter, impurity.
5. High pressure pump-- Provide the high pressure to RO membrane(at least 2.0 Mpa).
6. RO system--RO system is the main part of pure water treatment plant. The RO membrane's desalt rate can reach as high as 99%, it is capable of removing over 99% of ions, bacteria, particles and 98% of organic.
Parameters
1. Operating Pressure: < 300 psig
2. Maximum Recovery: 50% - 75%
3. Nominal Rejection: 95-99%
4. Operating Temperature: 2-35 ºC
5. Minimum Inlet Pressure: 30 psig
6. Design Temperature: 25 ºC
