Product Details:
Payment & Shipping Terms:
|
| Capacity: | 6000BPH(500ml) | Weight: | 3500kg |
|---|---|---|---|
| Filling Type: | Normal Pressure | Warranty: | One Year For Free |
| Control: | PLC+touch Screen | Power: | 5.03kw |
| Packaging Type: | Barrel, Bottles | Filling Temperature: | Room Temperature |
| High Light: | mineral water filling machine,automatic water filling machine |
||
Introduction of CGF18-18-6 water filling machine
The equipment is used in production of non-gas drink of mineral-pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface normal pressure filling is used. The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There is once time of internal and external washing, the efficiency of bottle washing is high.
The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.
The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.
The frequency changing technology is used to adjust the operation speed steplessly. The production capacity can be displayed digitally and can be adjusted conveniently.
Feature
1. The equipment is used in production of bottled non-carbonated drink of fruit juice, fruit wine, mineral water and pure water.
2. Rinsing, filling and capping are integrated in one machine.
3. The liquid filling technology of gravity which learned from latest technology from Japan and Germany is used in the design.
4. The filling is fast.
5. The fluid control is stability.
6. There is non-drip phenomenon.
7. Spring cramps are used in the bottle rinsing process. The empty bottles can be turned over 180° Along the conveying rail.
8. Rinsing the bottles inside and outside. The efficiency of bottle rinsing is high.
9. The magnetic torque is used for screw capping. The power of screw capping can also be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged. The capping is reliable.
10. The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. The machine will be stopped automatically. When bottles are cramped wrongly or when caps are not available.
Technical parameters
| Model | CGF16-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 |
| Production capacity(500ml)(b/h) | 2000-4000 | 4000-6000 | 8000-10000 | 12000-15000(0.5L) |
| Filling precision | ≤±5MM(Liquid Level) | |||
| Polyester bottle standard(mm) | Bottle diameter40-80; | |||
| Height | Height:130-280 | (Height):150-320 | ||
| Suitable cap shape | Plastic Screw Cap | |||
| Water pressure of Washing bottle(MPa) | 0.18 | |||
| Water consumption for Water bottle (kg/h) | 800 | 1600 | 2500 | 3500 |
| Spraying position | 5 | 5 | 6 | 12 |
| Dripping bottle position | 3 | 3 | 3.5 | 7 |
| Gas source pressure(Mpa) | normal pressure | |||
| Gas consumption(m3/mm) | 0.3 | 0.3 | 0.4 | 0.5 |
| Total power | 4.23 | 5.03 | 6.57 | 8.63 |
| Total weight | 2000 | 3500 | 5500 | 8000 |
| Dimension(L*W*H)mm | 2100×1500×2200 | 2450×1800×2200 | 2750×2180×2200 |
3500×2200×2250 |
