0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H

China 0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier
0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier 0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier 0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier 0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier 0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H supplier

Large Image :  0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: CGF24-24-8

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard wooden Boxes
Delivery Time: 30-45 working days
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Dimension(L*W*H): 2750*2180*2200mm Warranty: One Year For Free
Control System: PLC+touch Screen Filling Material: Stainless Steel 304
Atumatic Grade: Fully-automatic Power: 6.57kw
Bottle Type: Pet / Plastic Bottle Voltage: 380V/50Hz



Automatic 0.2-2L Plastic Bottle Drinking Water Machine Complete Filling Line



Introduction

This series of mineral Water Filling Machine are applied to the production of pure water, mineral water, it integrates bottle washing, filling and capping into one body of this machine. It is very convenient to change bottle size by means of advanced bottle conveying technology--bottleneck clamping & bottle suspending technology.

Main Featur

1. This machine has a compact structure, perfect control system, easy to operate and highly automated

2. The parts contact with product is made of quality SUS, anti-corrosive, and easy to clean.

3. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.

4. The capping head adopts constant torque magnetic device to guarantee capping quality and impact cap.

5. This machine has a high efficient cap arranging system, perfect cap feeding and protection device.

6. Equipped with perfect clean management system to ensure the bottle clean.

7. Only by changing the star-wheel, can realize to fill the changed bottle shape.

8. The machine adopts perfect overload protective device can ensure the operator and machine safe.

9. This machine adopts adjustable frequency converter.

10. The main electric components, frequency, photoelectric switch, proximity switch, electric control valves all adopt imported components, which can ensure the quality performance.

11. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.

12. The electric components and pneumatic components are all introduced from world famous brand products.

Technical parameter

Model CGF24-24-8
Production capacity(500ml)(b/h) 8000-10000
Filling precision ≤±5MM(Liquid Level)
Polyester bottle standard(mm) Bottle diameter40-80;
Height Height:130-280
Suitable cap shape Plastic Screw Cap
Water pressure of Washing bottle(MPa) 0.18
Water consumption for Water bottle (kg/h) 800
Spraying position 6
Dripping bottle position 3.5
Gas source pressure(Mpa) normal pressure
Gas consumption(m3/mm) 0.4
Total power 6.57
Total weight 5500
Dimension(L*W*H) 2750*2180*2200

0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H
0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H
0.2-2L Mineral Drinking Water Automatic Bottle Filling Machine 8000-10000b/H
