CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine

CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine
CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine

Large Image :  CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine

Product Details:
Place of Origin: China, mainland
Brand Name: JINYATE
Certification: ISO CE
Model Number: CGF16-12-6
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: pls inquiry
Delivery Time: 35 working days
Supply Ability: 99 sets per year
Detailed Product Description
Product Name: Water Bottle Filling Machine Function: Rinsing Filling Capping
Model Type: Tri-monobloc Suitable Bottle: PET Plastic Bottle
Filling Material: Water, Juice, Tea, Still Drink Capacity: 4000BPH(500ml)
Material: SUS304 Control: PLC+Transducer
High Light:

automatic bottling machine

,

liquid bottle filling machine

CGF16-12-6 4000BPH 250-2000ml Bottled Water Filling



Machine Turkey / Line



Machine description



This machine is a tri-monobloc, it integrates rinser filler and capper in



one monobloc, suitable for PET bottled water, juice, tea or other still



drink. It's rough capacity is 4000BPH(500ml), 2500BPH(1000ml),



2000BPH(2000ml).





Besides this filling machine, we can supply all complete line plants:



water treatment system; filling system; end-line package system



Technical parameter

Model CGF16-12-6
Capacity 4000bph (500ml PET bottle)
Bottle Height 150-320mm
Bottle Diameter 40-108mm
Filling Tenperature ambient
Filling Technology gravity filling
Applications purified water,mineral water, juice, still drink
Power supply 380V 50Hz 3Phases or customized
Total power 4.23KW
Dimension 2150*1500*2300mm
Weight 3000kg



Machine pictures



Overall look

CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine 0

internal look

CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine 1



Filler station

CGF16-12-6 4000BPH 250-2000ml Automatic Bottle Filling Machine 2



characters

1. The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.

2. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.

3. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably.





If you want to get precise quotation, pls leave your capacity here,

more details i know more exact the proposal is... ...
