3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part

China 3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part supplier
3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part supplier 3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part supplier 3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part supplier 3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part supplier

Large Image :  3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part

Product Details:

Place of Origin: China(Mainland)
Brand Name: JYT
Certification: CE SGS
Model Number: JYT

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: standard wooden cases
Delivery Time: 35 working days
Supply Ability: 99 sets per year
Contact Now
Detailed Product Description
Product Name: Bottle Blow Molding Machine Type: Semi Auto
Bottle Size: 100-6000ml Capacity: 1000B/H
Voltage: 380v 50hz 3phases Material: Stainless Steel



Semi Automatic 1000bph PET Bottle Extrusion Blow Molding



Machine





features



1. Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.

2. Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high



temperature.

3. Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet



different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It



provides sufficient steady high pressure to bloww large irregular shape bottles.

4. Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.

5. Operated step-by-step and in semi-auto maode.

6. Wide-mouth jar and hot-fill bottles can also be made.





product description



Bottle Blowing Machine:,Operated step-by-step and in semi-auto maode.Wide-mouth jar and hot-fill



bottles can also be made.


JYT-880 Stretch Blow Molding Machine is suitable to produce different shapes of PET/PC/PE bottles. It



can blow from 100ml to 6000ml bottles and is widely used to produce mineral water bottles,carbonater soft



drink bottles,juice bottles,medical botties,cosmetic and oil bottles etc.







technical parameter





TYPE
ITEM
MEASUREMENT
HZ-880 Standard type
END PRODUCT
Material
/
PET/PP/PE/PC
Volume
L
0.05-2.5 (2-cavity)
3-6 (1-cavity)
Theoretical output
Pcs/h
0.05-2.5L/850
3-6L/400
Max.length
mm
360
max.diameter
mm
180
MOULD PLATE
Max.mould plate
dimension(L×H)
mm
420*500
Max.mould thickness
mm
160-240
Clamping force
KN
90
Mold opening stroke (adjustable)
mm
200
AUXILARY
High pressure Compressor M3/M pa
KW
>=0.7/3.0*2sets 22
Precision air filters
M3/M pa
>=1.0/3.0*2pcs
MAIN MACHINE ELECTRICITY
Power
KW
12
Voltage/Frequency
V/HZ
220-380/50-60
MACHINE SIZE
AND WEIGHT
Main body dimension(L×W×H)
M
1.45*0.6*1.75
Main body weight
T
0.6
Conveyor dimension(L*W*H)
M
1.40*0.62*1.25
Conveyor weight
T







product pictures



3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part

3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part

3 Phases Extrusion Bottle Blowing Machine 12KW With Pneumatic Acting Part
