6.57KW Power Carbonated Drink Filling Machine PE Srew Cap For Gas Contained Beverage

Certification
China Zhangjiagang Jinyate Machinery Co., Ltd certification
China Zhangjiagang Jinyate Machinery Co., Ltd certification
Customer Reviews
Your machine quality is very good and technical team very professional, hope our products sell well!

—— Shiferaw Habte

I have worked with them for five years, their juice and carbonated machine help me spread my busniess acorss Africa, this year we place an 24000BPH carbonated line, looking forward to the machine installation in our factory early.

—— Umesh

I'm Online Chat Now

6.57KW Power Carbonated Drink Filling Machine PE Srew Cap For Gas Contained Beverage

6.57KW Power Carbonated Drink Filling Machine PE Srew Cap For Gas Contained Beverage
6.57KW Power Carbonated Drink Filling Machine PE Srew Cap For Gas Contained Beverage

Large Image :  6.57KW Power Carbonated Drink Filling Machine PE Srew Cap For Gas Contained Beverage

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: DGCF24-24-8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard Wooden Boxes
Delivery Time: 30-45 working days
Supply Ability: 10 Set/Sets per Month
Detailed Product Description
Power: 6.57kw Overall Dimension(L*W*H): 2750*2180*2200mm
Warranty: 1 Year For Free Material: Food Grade Stainless Steel 304
Voltage: 380V 50Hz Driven Type: Electric
Filling Pressure: Balanced Pressure Filling Filling Material: Gas Contained Beverage
High Light:

carbonated beverage bottling equipment

,

carbonated beverage filler





Cola / Carbonated Soft Drink Filling Machine For Energy Drink Plant /





Line





Introduction of carbonated drink filling machine



The machine is mainly used for filling carbonated drink. It combines rinsing and filling and capping as one



automatic body suitable for PET or other plastic bottles. The iso-pressure (iso-barometric) filling



technology is adopted enabling it to fill more efficiently and more stably with more output than the



machine of the same level from others.





Features of carbonated drink filling machine



1). This machine operates easily, with compact structure, perfect control system and high level of



automation.



2). The filling process of different types of bottles can be reached only by changing the star-wheel



3). The parts contacting with product is made of quality SUS, anti-corrosive, and easy to clean.



4). By adopting high speed filling valve, the liquid level is precise and no waste is to increase. That



guarantees the demand of modern filling technology.



5). The capping head adopts constant torque magnetic device to guarantee capping quality, without any



damage to the cap.



6). This machine has a highly efficient cap arranging system, perfect cap feeding and protection device.



7). All parts which contact with beverage are made with high quality polished stainless steel. The CIP



system offers automatically cleaning and sterilization of the filler.



8). Using PLC control the machine monitors, the filling liquid level automatically. Made up of high quality



stainless steel, it is sanitation. Operation and maintenance is convenient.







Technical parameter



Model: DCGF18-18-6 DCGF24-24-8 DCGF32-32-12 DCGF40-40-12
Capacity :500ml 4000-6000 6000-8000 8000-12000 12000-15000
Bottle shape: roud or square
PET bottle: (mm) (Bottle Diameter):φ50-.φ110mm (Height):150-340mm
Cap: PE srew cap
Filling precision: ≤±5mm
Filling pressure:(Mpa) 0.15-0.35 0.15-0.35 0.15-0.35 0.15-0.35
Rinsing pressure:(Mpa) 0.2-0.25 0.2-0.25 0.2-0.25 0.2-0.25
Power(KW) 5.03 6.57 8.07 8.07
Overall size:(mm) 2450*1800*2200 2750*2180*2200 3600*2200*2600 3600*2200*2600
Weight: (kg) 3000 4000 5000 6000



THis is Jane,If any requirments you need from me,please inquiry to me.If you



want to the detailed quotation,please leave me these message


1, bottle volume


2, bottle materail (machines for glass bottle and plastic bottle are different)


3, how many bottles per hour you want to produce ?


4, do you need this water filling machines only or whole water production line
