8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing

China 8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier
8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier 8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier 8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier 8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier 8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing supplier

Large Image :  8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: Jinyate
Certification: CE,ISO,SGS
Model Number: 8-8-3

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Standard wooden Boxes
Delivery Time: 30-45 working days
Payment Terms: L/C, T/T
Supply Ability: 15 Set/Sets per Month
Contact Now
Detailed Product Description
Automatic Grade: Fully Automatic Material Of Machine: Stainless Steel 304
Bottle Material: HDPE Bottle After-sales Service Provided: Engineers Available To Service Machinery Overseas
Warranty: One Year For Free Function: Bottle Washing Filling Sealing
Color: Silver Gray Weight: 1500kg
Power: 3kw Overall Dimension(L*W*H): 1600*1500*2200mm





8-8-3 Corn Juice 1.5L HDPE Bottle Hot Filling Aluminum Foil Sealing







Machine






Usage:



Washing, filling and aluminum foil sealing 3 in 1 monobloc is used for hot filling liquid,juice,water into



PET,plastic,HDPE bottle. Full automatically;





Primary features:



1. Compact conformation, good shape, cozy operation, excellent automaticity and poor labor intensity.



Only exchanging “star wheel”, ”feeding screw” and “arc guide plate” while exchanging model of bottle to



be need.



2. The all parts directly contacted with media are all adopted with food stage stainless steel without dead



angle, so they can be cleaned easily.



3. Adopting advanced valve to control the inlet flow rate of liquids. It can keep the slight turbulence of



liquids level in the solution barrel and ensure the accuracy in filling.



4. Closing feeding valve automatically while no bottle on machine avoiding the loss of aqueous feet. Filling



automatically with a high speed and the control of liquids level is accurate.



5. High filling speed and mass flow rate, high precision of filling valve and control of liquids level is



accurate and without loss.



6. The “capping head” is adopted magnetic-constant-torque device to ensure the high capping quality



and without damages.



7. Adopting efficient cap settling system which carried perfect cap feeding and protection device.



8. It is adopted spiral descent fashion for the support plate for bottom of bottle at the outlet thumb wheel.



And to adjust the input height is not necessary for exchanging model of bottle.



9. Carried the perfect protection system to overload; it can be used to protect facilities and operators



efficiently.



10. Because of applying touch screen for operation, it is possible to realize man-machine conversation



whereas the status of device running is clear at a glance.



11. The primary electric components such as touch screenPLCtransducer etc. are all adopted with world



famous products.





Technical parameter



Model 8-8-3
Production capacity(500ml)(b/h) 2000-4000
Filling precision ≤±5MM(Liquid Level)
Polyester bottle standard(mm) Bottle diameter40-80
Height(mm) Height:130-280
Suitable cap shape Plastic Screw Cap
Water pressure of Washing bottle(MPa)

0.18

Water consumption for Water bottle (kg/h) 800
Spraying position 5
Dripping bottle position 3
Gas source pressure(Mpa)

normal pressure

Gas consumption(m3/mm) 0.3
Total power(kw) 3
Total weight(kg) 1500
Dimension(L*W*H) 1600*1500*2200mm



Image show



Aluminum foil sealing machine



8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing



8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing



Outside look



8-8-3 Corn Juice Bottle Filling Machine 1.5L HDPE Bottle With Aluminum Foil Sealing
