Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine

China Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine supplier
Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine supplier Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine supplier Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine supplier Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine supplier

Large Image :  Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine

Product Details:

Place of Origin: China(mainlande)
Brand Name: JIAYUAN
Certification: CE SGS
Model Number: DCGF

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: PE film wrapping, standard wooden cases package
Delivery Time: 35 working days
Supply Ability: 90 sets per hour
Contact Now
Detailed Product Description
Product Name: Carbonated Beverage Filling Machine Function: Rising Filling Capping
Capacity: 3000-24000B/H Filling Type: Isobaric Filling
Filling Material: Carbonated Drink, Soda Water, Soft Drink, Energy Drink Etc Suitable Bottle: PET Bottle, Polyester Bottle
Material: SUS304 Voltage: Customized
Spare Parts: Free Warranty: 1 Year



Automatic Energy Drink Making Machine/ Carbonated Soft Drink



Filling Machine





Description



This DCGF serial machine special for carbonated beverage filling, combined with rinsing,



filling and capping. It is innovated and designed in the requirement of carbonated beverage



techniques, on the bases of introducing, digesting and absorbing advanced technology



abroad. It is reasonable in structure, safe to operate and easy to maintain, which is an ideal



choice for beverage producers.





technical parameter



Model DCGF16-12-6 DCGF18-18-6 DCGF24-24-8 DCGF32-32-10 DCGF40-40-12 DCGF50-50-15
Number of rising heads 16 18 24 32 40 50
Number of filling heads 12 18 24 32 40 50
Number of capping heads 6 6 8 10 12 15
Bottle standard(mm)

Diameter:Φ50-Φ108

Height:150-320

Rated production capacity(500ml) 2000BPH 4000BPH 7000BPH 8000BPH 10000BPH 12000BPH
Installed capacity(KW) 3.8 4.3 6.5 8.7 9.5 12








Feature



1). Compact structured, good-looking, and easy to operate and highly automated.



2). Air conveyor is directly linked with feed-in starwheels, making it easier to change bottles without screws



and conveyor chains.



3). Bottles are transferred in the manner of clamping neck. Bottles can be changed through some replacement



of steel clamps, which instead of adjusting the height of machine.



4). Rinser-clamp which special design is strong and endurable, no contact with bottle-mouth, to



prevent pollution.



5). Highly effective spraying nozzles equipped on the rinser-clamp can rinse every side of inner bottle and save



water. Accessories which contact with material are all made of stainless steel, no dead angles and easy to clean



up.





machine pictures



Washing system: the holder will catch the bottle and turn 180 degrees in order to spray medium into



bottle to finish a flush program in order to ensure bottle clean. Also in accordance with the requirements



of local users on the realization of disinfectant, the system will flush the bottle secondly to improve the



product.



Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine





Filling system: the main components includes feeding tanks, piping, filling valve, filling head,gear,motor



and control system.the control system is the main brain of the machine,it controls filling,motor,conveyor



etc,the medium comes from tank goes to filling valves through piping,filling head connect with bottle then



valve open,medium fills the bottle.



Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine



capping system:The capping system is controlled by PLC,when bottle in place it cappings immediately.



Compact Structured Bottling Line Equipment , Carbonated Soft Drink Filling Machine





we are professional in beverage filling machine, if you tell us your



request, we will offer you the most commercial proposal... ...
